Application guides for BT578 RS232 Bluetooth adapter

查看数: 21716 | 评论数: 6 | 收藏 0
关灯 | 提示:支持键盘翻页<-左 右->
    组图打开中,请稍候......
发布时间: 2021-2-5 21:45

正文摘要:

Change the serial baud rate of BT578(V2/V3) adapter It's easy to change the serial baud rate of BT578(V2/V3) adapter, just 3 steps: 1,  Connect BT578 to Windows XP/7/8/10 computer via DB9 ...

回复

admin 发表于 2022-1-27 01:12:29

Frequently Asked Questions

Q1: I am trying to configure the adapter to change the BAUD rate. I downloaded your android app. I successfully connected to the BT578_BLE on the app. However, when I send a AT command there is no reply. When I look at the adapter, the power light is on,  the bluetooth light is solid once I connect to the app. When I send a AT command the Serial Data Activity LED briefly flashes and then turns off. I have tried to send the AT commands while pressing and holding the  AT command button but I get no reply. Could you please advise?

A1: BT578V2 does not support AT command via Bluetooth wireless connection, you have to send AT command via RS232 physical connection.
You must connect BT578V2 to a serial port of your computer to send AT command.  If your PC does not have a serial port, please buy a USB-RS232  cable to add a physical COM port to your computer.
Our another product, BT580, can support remote Bluetooth AT commands. http://www.irxon.com/english/products/bt580_en.htm


Q2: Windows 11 can't find BT578 V3.

A2: If you don't see your BT578/BT579/BT580 device displayed in the list of devices in Windows 11, you may need to set your Bluetooth devices discovery setting to Advanced.

1. Select Start  > Settings  > Bluetooth & devices  > Devices .

2. Under Device settings > Bluetooth devices discovery, choose one of the following from the drop-down list:
Default—displays common Bluetooth devices
Advanced—displays all types of Bluetooth devices

ycp 发表于 2021-2-7 10:58:41

About Android APP location permission

In Android 6.0 and higher version, a coarse location permission is needed to run Bluetooth searching.

When you run "ATBlue" or "Blueterminal" for the first time, please give the APP location permission, select "While Using" or "Allow".
